Parameters of the light source and optical power meter

Fibre interconnection and data room reference Published 18 May 2025

Use this reference to prepare product questions for FD SOLUCIONES. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Optical power meters require compatible light sources with stable output across specific wavelengths, available in various models for single-mode and multimode fiber testing.

Key Specifications of Light Sources

Wavelength Range: Light sources for optical power meters typically cover 850 nm, 980 nm, 1270–1650 nm, depending on the application. For example, Tempo Communications sources support 850, 980, 1270, 1300, 1310, 1490, 1550, 1577, 1623, and 1650 nm, while Anritsu CMA5 sources cover 850/1300 nm for datacom and 1310/1550/1625 nm for WDM applications. Output Type: Sources may use lasers or LEDs, with dual or triple wavelength options for multi-application testing.

Power Stability: High stability is essential for accurate insertion loss and attenuation measurements. Many sources are designed for rugged field use and maintain consistent output under varying environmental conditions. Fiber Compatibility: Sources are compatible with single-mode (SM) and multimode (MM) fibers, often with interchangeable adapters for different connector types.

Popular Models and Kits

Tempo Communications: Offers OPM510 and OPM520 meters paired with dual/triple wavelength lasers or dual-wavelength LEDs. Kits include optical adapters, power supplies, and carry cases. Anritsu CMA5 Series: Economical, handheld light sources and power meters with auto-zeroing, tone detection, and multiple wavelength calibration.

Ideal for point-to-point attenuation measurements in datacom, WDM, and FTTx networks.

Dimension OP

M Series: Includes High-Performance, High-Speed, High-Power, High-Sensitivity, and Cost-Effective modules compatible with ALPHA and OMEGA test platforms. Wavelength range 850–1650 nm, with high-speed data acquisition up to 10 kHz and buffer sizes up to 10 million measurements per channel.

AF

L Contractor Series: Rugged, palm-sized units for field use, supporting network insertion loss, continuity checks, and fiber identification. Features include stored optical references and auto-detection of test tones. Thorlabs Power and Energy Meters: Modular consoles (PM100A, PM100D2, PM100D3, PM400, PM5020) with NIST-traceable calibration, multiple sensor heads, and compatibility with single- and dual-channel measurements.

Sensor calibration is stored in the head for easy interchangeability.

Additional Considerations

Ruggedness and Portability: Field testing often requires compact, lightweight, and IP-rated devices for durability. Calibration and Accuracy: Many models provide factory-calibrated wavelengths and support user-configurable trigger inputs and analog outputs for automated testing. Integration: Some systems, like Dimension OPM modules, allow software-controlled automated testing and integration with other optical test modules for laboratory or industrial applications.

In summary, selecting a light source for an optical power meter depends on the wavelength requirements, fiber type, measurement accuracy, and intended environment. Manufacturers like Tempo Communications, Anritsu, Dimension, AFL, and Thorlabs offer a range of models and kits tailored for both field and laboratory applications, ensuring reliable and precise optical power measurements.
