Seeking to purchase cable tray tees and elbows

Fibre interconnection and data room reference Published 26 Nov 2024

Use this reference to prepare product questions for FD SOLUCIONES. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Cable tray tees and elbows are available in a variety of materials, finishes, and sizes to suit light, medium, and heavy-duty applications, with suppliers like Metsec, Hubbell, King Power Technology, and Atkore offering comprehensive options.

Material and Finish Options

Mild Steel Pre-

Galvanised (PG): Standard option for general indoor use.

Mild Steel Hot-

Dip Galvanised (HDG): Provides enhanced corrosion resistance for outdoor or humid environments. Stainless Steel Grade 1. 4404 (316L): Ideal for highly corrosive or chemical-prone environments.

Aluminum: Lightweight and corrosion-resistant, suitable for atmospheric exposure.

Types of Tees and Elbows

Equal Tees: All three branches have the same width, used for uniform cable distribution. Unequal Tees: Branch widths differ, suitable for connecting main and secondary cable runs. Horizontal Elbows: Change cable direction along the same plane.

Vertical Elbows: Change cable direction between different elevations. Reducing Tees and Elbows: Allow transition between different tray widths. Cross Pieces: Enable four-way cable routing.

Size and Load Considerations

Widths: Typically range from 50mm to 900mm, depending on cable volume. Height Options: Common heights include 50mm, 70mm, 100mm, and 120mm. Load Class: Choose fittings compatible with the tray's NEMA class (Class 1–4) to ensure structural integrity.

Supplier Recommendations

Metsec: Offers a wide range of tees, crossovers, and elbows for light, medium, and heavy-duty trays with multiple finishes and covers. Hubbell: NEXTFRAME® Ladder Tray system provides modular elbows, tees, and cross pieces for data centers and industrial applications. King Power Technology: Provides elbows, horizontal and vertical tees, reducers, and covers in various sizes and surface treatments.

Atkore: I-BEAM ladder tray fittings, including horizontal reducing tees and elbows, compatible with NEMA standard trays.

Additional Considerations

Covers: Closed or ventilated covers are available to protect cables from dust or environmental exposure. Installation: Ensure proper bend radius and support spacing to prevent cable damage. Compatibility: Verify that elbows and tees match the tray type (ladder, solid-bottom, ventilated) and NEMA class for safe and efficient installation.

By selecting the appropriate material, finish, size, and load class, and sourcing from reputable suppliers like Metsec, Hubbell, King Power Technology, or Atkore, you can ensure reliable and durable cable tray installations for a wide range of applications.
