Nordic Cable Tray Size Specifications Table

Nordic Wire Tray's X-Tray cable trays are available in standard widths, depths, and lengths, with flexible customization to meet specific project requirements.

Standard Dimensions Overview

Cable tray dimensions generally include width, depth (side rail height), length, and material thickness, which affect cable capacity, heat dissipation, and structural load. Standard widths typically range from 100 mm to 600 mm for small to large installations, while depths vary from 50 mm to 150 mm, depending on the tray type and load requirements. Standard lengths are usually 2 to 3 meters per section, allowing easy transport and installation.

Material thickness influences load capacity and long-term durability, with thicker trays supporting heavier cable loads and longer spans.

Nordic X-

Tray Specifics

Nordic Wire Tray's X-Tray series is designed for industrial and commercial applications, offering: Customizable widths and depths to suit specific cable volumes and installation environments. High load capacity for heavy-duty applications, with trays engineered to withstand harsh conditions. Flexible lengths and easy cutting on-site using wire cutting machines, allowing adaptation to unique layouts.

Longest bracket spacing in the market, reducing the number of supports needed and simplifying installation. Multiple surface treatments including stainless steel options for corrosion resistance.

Practical Considerations

When selecting Nordic cable trays: Width selection should match the total cable fill while allowing airflow for heat dissipation. Depth should accommodate vertical stacking of cables without overcrowding. Material thickness must be sufficient for the expected load and span between supports.

Customization is available for projects with unusual layouts or high-density cabling, ensuring compliance with IEC 61537 and other standards. Nordic Wire Tray emphasizes that while their standard range covers most needs, custom solutions are readily available to meet unique project requirements, ensuring both safety and efficiency in cable management.
