200 Cable Tray Specifications

Fibre interconnection and data room reference Published 07 Jul 2026

Use this reference to prepare product questions for FD SOLUCIONES. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Cable Tray 200 refers to cable management trays with a width of 200 mm, available in various heights and materials, designed for organized cable routing and secure installation.

Dimensions and Material

Width: 200 mm standard for all variants. Height: Common heights include 42 mm, 60 mm, and other options depending on the manufacturer. Length: Typically 2 meters for standard trays, with some models up to 3 meters.

Material: Options include powder-coated steel, galvanized steel, and hot-dip galvanized steel for corrosion resistance. Material Thickness: For galvanized trays, thickness is commonly 0. 90 mm.

Mounting and Installation

Vertical and Horizontal Use: Cable Tray 200 can be used for vertical cable management or horizontal routing. Mounting Options: Fixed to upper and lower frames with threaded mounting rails for stepless depth adjustment. Wall and support brackets (types MWA 12, AW 15, AW G 15) can be bolted for secure installation.

Accessories: Cables can be secured using tie-wraps, Velcro, or toolless mount plastic cable rings. Covers are available for additional protection. Connection: Trays can be connected using screws or T-pieces for cross connections.

Fire Resistance and Certifications

Fire Resistance: Some trays meet E90 fire resistance standards. Certifications: CE marking, DIN 4102-12: 1998, ISO 14001: 2015, ISO 45001: 2018. Certain models also provide magnetic shielding up to 50 dB with covers.

Additional Features

Flexible Adjustment: Stepless depth adjustment allows precise placement in frames. Durability: Galvanized and hot-dip galvanized options provide long-term corrosion protection. Compatibility: Designed to integrate with standard cable management systems and accessories for organized routing.

Cable Tray 200 systems are suitable for industrial, commercial, and data center applications where organized, safe, and flexible cable management is required. They provide a combination of mechanical strength, fire safety, and ease of installation.
