Price of Elbow and Right Angle Cable Trays

Right-angle and elbow cable trays typically range from $15 to $150 per piece depending on material, size, and duty rating. Overview of Cable Tray ElbowsRight-angle and elbow cable trays are fittings used to change the direction of cable runs in electrical installations. They are available in: Horizontal elbows (90° bends along the horizontal plane)Vertical elbows (90° bends along the vertical plane)Inside and outside corners for routing around obstacles Materials commonly used include hot-dip galvanized steel, stainless steel, aluminum, and halogen-free plastic, each affecting the price.

Duty ratings (light, medium, heavy) also influence cost, with heavy-duty trays supporting larger or more numerous cables.

Typical Price Ranges

While exact prices vary by supplier, size, and material, typical market ranges are: Light-duty plastic or aluminum elbows: $15–$40 per pieceMedium-duty galvanized steel elbows: $40–$80 per pieceHeavy-duty stainless steel or large-size steel elbows: $80–$150 per piece Additional factors affecting price include tray width, height, and surface treatment (e.g., powder coating or hot-dip galvanization),. Accessories like couplers, tees, and brackets may add $5–$30 per component. Supplier OptionsEkabel24 offers a wide range of steel and plastic cable trays compliant with DIN EN 61537 standards.

Bahra Electric provides modular metal and non-metallic trays suitable for commercial and industrial installations.

R

S Components stocks high-quality tray accessories, including elbows, supports, and hangers from brands like Legrand and Schneider Electric. McMaster-Carr lists over 850 cable tray products, including elbows and right-angle fittings, with same-day delivery options.

Recommendations

Choose material and duty rating based on cable load and environmental conditions. Consider modular systems for easier future expansion. Compare suppliers for bulk discounts and shipping costs.

By understanding these factors, you can estimate costs and select the right elbow or right-angle cable tray for your project efficiently.
