Price of irregularly shaped cable tray parts

Irregularly shaped cable tray components typically range from $50 to $435 per piece, depending on size, material, and configuration. Pricing Overview1. U.

S.

Suppliers

Platt Electric Supply lists shaped wire basket trays and radius drops from $59. 80 to $434. 17 per section, depending on dimensions and material (steel, pre-galvanized, or powder-coated) (Platt Electric Supply).

Graybar offers radius drops, elbows, and custom fittings in the range of $59. 80 to $434. 17, with options for wire mesh, ladder, and solid-bottom trays (Graybar).

McMaster-Carr provides formable zinc-plated steel trays and fittings, including horizontal and vertical elbows, tees, and drop-outs, with prices generally starting around $60 per piece for small aluminum or steel elbows and increasing with size and load capacity (McMaster-Carr). 2. International Suppliersm.

G. Cable Industries (India) lists perforated, ladder, and channel-type cable trays with coupler plates for irregular sections. Prices for small fittings start at ₹16–30 per piece, while larger or multi-compartment trays can cost several hundred rupees per unit, depending on width, height, and material (GI, HDGI, aluminum, FRP) (m.

G. Cable Industries).

Factors Affecting Price

Material: Stainless steel and aluminum are more expensive than hot-dip galvanized or carbon steel trays due to corrosion resistance and weight considerations. Size and Dimensions: Wider, deeper, or longer trays and fittings cost more. Complexity: Custom bends, radius drops, and multi-compartment trays increase fabrication costs.

Load Capacity: Components rated for higher cable loads are priced higher. Finish: Powder-coated or pre-galvanized finishes add to the cost.

Practical Guidance

For budgeting, expect small radius drops or elbows to start around $50–$100, medium-sized shaped trays $100–$250, and large or heavy-duty components $300–$435 in the U. S. market. For bulk orders or international sourcing, prices can be significantly lower, but shipping and import duties should be considered.

Always verify compatibility with your existing tray system (ladder, wire mesh, solid-bottom) and ensure proper grounding for metal trays. By considering material, size, and supplier, you can estimate costs for irregularly shaped cable tray components and plan your procurement accordingly.
